Natural Wooden Frame Glass Partition System | Strähle

Modulares Bürointerieur mit Glastrennwand aus Holzrahmen. Die flexible Trennung sorgt für viel Licht und Raumgefühl.

Showroom Waiblingen

The flush glass partition with an elegant wooden frame construction significantly increases the proportion of renewable wood-based materials in the system wall. System 2000_Nature supports interior design concepts that aim to create a warm, cosy atmosphere. The wooden frames consist of a real wood profile that is veneered. The modular design ensures that the system can be easily and economically adapted to new requirements at any time and is inherently recyclable.

Design: Design with mullions
Construction: Flush-fronted timber frame glazing
Element types: Fully glazed, toplight, balustrade, solid wall
Surface:
Veneered solid wood timber frames (oak veneer as standard)
Glass wall (single-pane safety glass/laminated safety glass/insulating glass)
Solid wall (melamine, veneer, HPL, lacquer)
Wall thickness: 100 mm
Visible wight: Vertical, 35 mm at the bottom, 50 mm at the top

High proportion of renewable wood-based materials
Excellent conversion capability and re-usability
Easily separable materials (dismantling, recycling)
Materials can be recycled after use
Harmless main material types: glass, aluminium, steel, wood-based materials
Building certifications possible with this system

Offener Wohn- und Küchenbereich mit minimalistischen weißen Schränken, Glasvitrinen und hellen Holzmöbeln. Eine Frau steht im Türbereich.

Picture gallery

Durchsichtige Bürotrennwände mit Holzrahmen definieren einen modernen, hellen Arbeitsbereich.

Modernes Bürointerieur mit großflächigem, hellen Trennwandsystem. Holz- und Glaspaneele trennen den Arbeitsbereich optisch und akustisch ab.

Helle Holztür kombiniert mit angrenzenden Glastrennwänden in einem modernen Innenausbau.

Eine Kombination aus hellholzfarbenen Türen und einem durchgehenden Glas-Trennwandsystem in modernen Büroräumen.

Moderne Raumteilung durch Holz- und Glas-Trennwände. Die Architektur lässt Licht in ein helles, wohnliches Interieur strömen.

Frau vor einem modernen Trennwandsystem: Spiegel, Holzrahmen und weiße Regalböden gestalten den Innenraum.

Natural materials
Elegant timber-framed construction using profiles veneered with real wood; high proportion of renewable wood-based materials

Sustainable system concept
Modular design enables repurposing, reusability and recyclability

High acoustic performance
Excellent sound insulation for transparent room structures – Rwp 52 dB to Rwp 56 dB

Planning reliability & system compatibility
Based on the System 2000 modular system; can be combined with other System 2000 wall and door solutions

Technical details

Design

Design with mullions

Options

Flush-fronted timber frame glazing

Element types

Fully glazed, toplight, balustrade, solid wall

Surface

Veneered solid wood timber frames (oak veneer as standard) Glass wall (single-pane safety glass/laminated safety glass/insulating glass) Solid wall (melamine, veneer, HPL, lacquer)

Wall thickness

100 mm

Visible width

Vertical, 35 mm at the bottom, 50 mm at the top

Sound insulation

Glass wall: of up to Rwp 52 dB; Solid wall: of up to Rwp 56 dB;

Fire prevention

Glass wall: F0; Solid wall: F 30 / F 90

Accessories

Acoustic absorbers, blinds, climate control elements, accessory system
