Aluminium frame door

AR40/ AR64/ AR100
ic-cta-arrow ic-cta-arrow

Aluminium frame door AR 40

Product information

Single-leaf door element in frame design with glass filling

Technical Data

  • Door panel: All-glass frame door panel with slim aluminium profiles, 75 mm visible width
  • Door thickness: 40 mm
  • Door frame: Anodised aluminium E6/EV1
  • Optional functions:
    Sound insulation up to 37 dB Rwp (SSK II)/ Access control / Emergency exit function / Emergency exit locking / Lock monitoring
  • Compatible with Systems: 2000, 2300, 3400, MTS

Sound insulation

bis Rw,P 37 dB

Fire protection

T0

Pictures gallery

Technical Details

TürblattDoor panel:

All-glass frame door panel with slim aluminium profiles, 75 mm visible width

Door thickness:

40 mm

Door frame:

Anodised aluminium E6/EV1

Door fittings:

From Strähle collection

Sound insulation:

Up to Rw,P 37 dB

Fire protection:

T0

Connections:

Fitting in Strähle partition wall systems/ Fitting in concrete and masonry walls/ Fitting in drywalls

Optional functions:

Sound insulation up to 37 dB Rwp (SSK II)/ Access control/ Emergency exit function/ Emergency exit locking/ Lock monitoring

Compatible with Systems:

2000, 2300, 3400, MTS

Aluminium frame door AR 64

Product information

Single-leaf or double-leaf door element in frame design with insulating glass filling

Technical Data

  • Door panel: Fully glazed frame door panel with slim aluminium profiles, 90 mm visible width. Glazed using 38 mm thick acoustic isolation glass
  • Door thickness: 64 mm
  • Door frame: Anodised aluminium E6/EV1
  • Door fittings: From Strähle collection
  • Optional functions: Sound insulation up to 37 dB Rwp (SSK II)/ Access control/ Emergency exit function/ Emergency exit locking/ Lock monitoring

Sound insulation

bis Rw,P 37 dB

Fire protection

T0

Picture gallery

Technical Details

Door panel:

Fully glazed frame door panel with slim aluminium profiles, 90 mm visible width. Glazed using 38 mm thick acoustic isolation glass

Door thickness:

64 mm

Türzarge: Door frame:

Anodised aluminium E6/EV1

Door fittings:

From Strähle collection

Sound insulation:

Up to Rwp 37 dB

Fire protection:

T0

Connections:

Fitting in Strähle partition wall systems/ Fitting in concrete and masonry walls/ Fitting in drywalls

Optional functions:

Sound insulation up to 37 dB Rwp (SSK II)/ Access control/ Emergency exit function/ Emergency exit locking/ Lock monitoring

Compatible with Systems

2000, 2300, 3400, MTS

Aluminium frame door AR 100

Product information

Door element in aluminium frame design with double glazing fl ush bonded on both
sides, 6/8 mm laminated glass, visible frame width 95 mm

Technical Data

  • Door panel: Fully glazed frame door panel with slim aluminium profiles with 65/95 mm visible width . Double glazing with mit thoughened or laminated glass.
  • Door thickness: 100 mm
  • Door frame: Anodised aluminium E6/EV1
  • Door fittings: From Strähle collection
  • Optional functions: Access control/ Emergency exit function/ Emergency exit locking/ Lock monitoring

Sound insulation

Up to Rw,P 44 dB

Fire protection

T0

Picture gallery

Technical Details

Door panel:

Fully glazed frame door panel with slim aluminium profiles with 65/95 mm visible width . Double glazing with mit thoughened or laminated glass

Door thickness:

100 mm

Door frame:

Anodised aluminium E6/EV1

Door fittings:

From Strähle collection

Sound insulation:

Up to Rwp 44 dB

Fire protection:

T0

Connections:

Fitting in Strähle partition wall systems/ Fitting in concrete and masonry walls/ Fitting in drywalls

Optional functions:

Access control/ Emergency exit function/ Emergency exit locking/ Lock monitoring

Compatible with System:

2000, 2300, 3400, MTS
